45° Corner Unit

Typical Exterior Panel Dimension(s)

Length 25.56" x Width 9.56" x Height 12.25" (interlocked)
(Length 64.92 cm x Width 24.28 cm x Height 31.12 cm)

Note: part dimensions may vary slightly due to EPS material shrinkage (100% recyclable)

Typical Interior Panel Dimension(s)

Length 21.0" x Width 5.0" x Height 12.25" (interlocked)
(Length 53.34 cm x Width 12.7 cm x Height 31.12 cm)

Note: part dimensions may vary slightly due to EPS material shrinkage (100% recyclable)

Concrete Volume per Corner Unit

0.048 yd³ (0.036 m³)

Integra Foam panel(s) Material

Flame Retardant Type 2, Expanded Polystyrene (EPS), Density = 1.5 lb/ft³ (pcf) (24.14 kg/m³)

Integra Plastic Insert(s) Material

High Impact Polystyrene (HIPS) (recycled material)

Unique and Special Interlocking Features of the Panels

Patented bi-directional and/or reversible (No top, bottom, left, or right hand side). Enables faster and more accurate installation and eliminates waste

Interlocking Design

Unique, patented friction and mechanical interlocks

Typical Fastening Studs / Strapping

Vertical 1⅝" (4.13 cm) wide located every 8" (20 cm) OC (with an additional located at exterior corner)

Exterior Surface Area

2.99 ft² (0.28 m²) (interlocked)

Interior Surface Area

2.21 ft² (0.20 m²) (interlocked)

Qtys / Area / Meters per Bundle – Exterior Corner Panels

16 panels/bundle
47.84 ft² (4.48 m²) of wall area (exterior face of wall, one side)

Qtys / Area / Meters per Bundle – Interior Corner Panels

16 panels/bundle
35.36 ft² (3.20 m²) of wall area (interior face of wall, one side)

Packaging

Poly-wrapped

Bundle Weight and Size – Exterior Panels

Approx. 28 lbs (12.7 kg)
H 25.5" x L 45.5" x W 23" (H 65 cm x L 116 cm x W 58 cm)

Bundle Weight and Size – Interior Panels

Approx. 26 lbs (11.8 kg)
H 25.5" x L 21.5" x W 34" (H 65 cm x L 55 cm x W 76 cm)
